Digisol
DIGISOL DG-MC5123S-PRLV12 – 100Base-TX/FX Single-Fiber Media Converter
₹8,200
₹9,200
11% OFF
You save ₹1,000 (11%)
The DIGISOL DG-MC5123S-PRLV12 is a Fast Ethernet Single-Fiber Media Converter designed to connect RJ45 Ethernet networks with optical fiber using just one fiber strand. It supports 100Base-TX to 100Base-FX conversion and works in both full-duplex and half-duplex modes. The converter uses different transmit and receive wavelengths for efficient single-fiber communication and includes LED indicators for easy network status checking.
Key Features
Single-fiber data transmission
100Base-TX to 100Base-FX conversion
Full and half-duplex operation
WDM wavelength-based communication
SC fiber connection
LED status monitoring
Product Specifications
Brand : DIGISOL
Model Name / Number : DG-MC5123S-PRLV12
Product Type : Fast Ethernet Optical Transceiver
Network Standard : IEEE 802.3u
Ethernet Standard : 100Base-TX
Fiber Standard : 100Base-FX
Fiber Type : Single-Mode Single Fiber
Fiber Connector : SC
Copper Connector : RJ45
Wavelength Pair : Tx 1310nm / Rx 1550nm or Tx 1550nm / Rx 1310nm
Duplex Mode : Full Duplex / Half Duplex
