Fibershot Mini OTDR Fiber Optic Tester – Up to 35 dB

Fibershot Mini OTDR is a lightweight and user-friendly fiber optic testing device designed for installation, maintenance and troubleshooting of optical fiber networks. Its compact design makes it convenient for field technicians, while the 5-inch HD display provides a clear view of test information. The device supports OTDR testing, Optical Power Meter (OPM), 10mW VFL and real-time testing, with Fiber Link Mapping and Pass/Fail functionality for easier fiber link evaluation. Depending on the selected model, it is available for Single Mode and PON applications with testing options up to 38 dB. With 16GB storage and capacity for up to 1,20,000 results, the Mini OTDR can be used for regular fiber testing and maintaining test records. Key Features: Lightweight and portable Mini OTDR design Up to 35 dB OTDR version as shown in the reference Built-in 10mW VFL Built-in Optical Power Meter Real-time OTDR testing Single Mode and PON model options 16GB result storage Suitable for fiber installation and maintenance work Specifications: Product Type- Mini OTDR Application- Fiber Optic Testing OTDR Dynamic Range- Up to 35 dB Small Event / Dead Zone- 1 m / 4 m Display- 5-inch HD Display Operation- Touch + Physical Keys VFL Power- 10 mW Model Range- Up to 38 dB, model dependent Result Storage- 16GB Result Capacity- Up to 1,20,000 Results
